Feature:

● Separate tunnel, It can scan high/low filter, optimize subwoofer or whole system output, so that it can have high sound quality and performance in any system.

● Every tunnel use "Neutrlk Speakon" output jack and 1/4 inch output jack, and 5-ways binding, Providing excellent connect flexibility.

● Providiing comprehensive protection measures include: switch, mute, DC detection, thermal protection, current limiting protection,and attenuator protection.

● System running efficiently, so that the AC power consumption and heating decrease, ultimately, the operating cost be decrease.

● Strengthen 2U/3U steel body, More reliable and more durable, light weigh make the transport and assembly easily.

P2500S performance parameters:
The main input voltage 220 v AC /;
8 Ω output power 275 w * 2;
4 Ω output power 400 w * 2;
Input impedance Ω 20 k;
The damping coefficient of the material 223
30 KHZ frequency response 20 hz - 20 KHZ, plus or minus dB
Total harmonic distortion of < 0.05%;
SNR > 98 db;
Protection function: over current, short circuit, over temperature protection and so on
12 kg weight;
Size 450 * 483 * 90 mm


P3500S performance parameters:
The main input voltage 220 v AC /;
8 Ω output power 350 w * 2;
4 Ω output power 500 w * 2;
Input impedance Ω 20 k;
The damping coefficient of the material 223
30 KHZ frequency response 20 hz - 20 KHZ, plus or minus dB
Total harmonic distortion of < 0.05%;
SNR > 98 db;
Protection function: over current, short circuit, over temperature protection and so on
15 kg weight;
Size 450 * 483 * 90 mm


P5000S performance parameters:
The main input voltage 220 v AC /;
8 Ω output power 500 w * 2;
4 Ω output power 650 w * 2;
Input impedance Ω 20 k;
The damping coefficient of the material 223
30 KHZ frequency response 20 hz - 20 KHZ, plus or minus dB
Total harmonic distortion of < 0.05%;
SNR > 98 db;
Protection function: over current, short circuit, over temperature protection and so on
18 kg weight;
Size 450 * 483 * 90 mm


P7000S performance parameters:
The main input voltage 220 v AC /;
8 Ω output power 600 w * 2;
4 Ω output power 900 w * 2;
Input impedance Ω 20 k;
The damping coefficient of the material 223
30 KHZ frequency response 20 hz - 20 KHZ, plus or minus dB
Total harmonic distortion of < 0.05%;
SNR > 98 db;
Protection function: over current, short circuit, over temperature protection and so on
Weight 20 kg;
Size 450 * 483 * 90 mm


P6500S performance parameters:
The main input voltage 220 v AC /;
8 Ω output power 500 w * 2;
4 Ω output power 650 w * 2;
Input impedance Ω 20 k;
The damping coefficient of the material 230
30 KHZ frequency response 20 hz - 20 KHZ, plus or minus dB
Total harmonic distortion of < 0.05%;
SNR > 103 db;
Protection function: over current, short circuit, over temperature protection and so on
18 kg weight;
Size 455 * 483 * 123 mm


P7500S performance parameters:
The main input voltage 220 v AC /;
8 Ω output power 650 w * 2;
4 Ω output power 900 w * 2;
Input impedance Ω 20 k;
The damping coefficient of the material 230
30 KHZ frequency response 20 hz - 20 KHZ, plus or minus dB
Total harmonic distortion of < 0.05%;
SNR > 103 db;
Protection function: over current, short circuit, over temperature protection and so on
Weight 20 kg;
Size 455 * 483 * 123 mm


P8500 performance parameters:
The main input voltage 220 v AC /;
8 Ω output power 800 w * 2;
4 Ω output power 1200 w * 2;
Input impedance Ω 20 k;
The damping coefficient of the material 230
30 KHZ frequency response 20 hz - 20 KHZ, plus or minus dB
Total harmonic distortion of < 0.05%;
SNR > 103 db;
Protection function: over current, short circuit, over temperature protection and so on
Weight 30 kg;
Size 455 * 483 * 123 mm


P9500S performance parameters:
The main input voltage 220 v AC /;
8 Ω output power 1000 w * 2;
4 Ω output power 1500 w * 2;
Input impedance Ω 20 k;
The damping coefficient of the material 230
30 KHZ frequency response 20 hz - 20 KHZ, plus or minus dB
Total harmonic distortion of < 0.05%;
SNR > 103 db;
Protection function: over current, short circuit, over temperature protection and so on
35 kg weight;
Size 455 * 483 * 123 mm
